Set Up GraphQL in Rails 7: Developer Tutorial

GraphQL is becoming increasingly popular as an alternative to REST APIs, offering more flexibility and efficiency in data fetching. In this guide, we'll walk through setting up GraphQL and GraphiQL in a Rails application, using practical examples from a real-world implementation.

Prerequisites

Ruby on Rails 7.2+
Ruby 3.3+
Basic understanding of Rails applications

Step 1: Adding Required Gems

First, add the necessary gems to your Gemfile:

gem 'graphql', '2.3.14'
gem 'graphiql-rails', '1.10.1'

Step 2: Installing GraphQL

Run the following commands to install GraphQL and generate the base files:

bundle install
rails generate graphql:install

This will create the basic GraphQL structure in your Rails application:

app/
└── graphql/
    ├── types/
    │   ├── base_object.rb
    │   ├── base_enum.rb
    │   ├── base_input_object.rb
    │   ├── base_interface.rb
    │   ├── base_scalar.rb
    │   ├── base_union.rb
    │   ├── query_type.rb
    │   └── mutation_type.rb
    ├── mutations/
    │   └── base_mutation.rb
    └── [your_app]_schema.rb

Step 3: Setting Up GraphQL Controller

Create a GraphQL controller to handle requests:

class GraphqlController < ApplicationController
  def execute
    variables = prepare_variables(params[:variables])
    query = params[:query]
    operation_name = params[:operationName]
    context = {
      current_user: current_user  # This comes from ApplicationController
    }
    result = YourAppSchema.execute(query,
                                 variables: variables,
                                 context: context,
                                 operation_name: operation_name)
    render json: result
  rescue StandardError => e
    raise e unless Rails.env.development?
    handle_error_in_development(e)
  end

  private
  # ... [rest of the controller code]
end

Authentication Setup

The current_user method is defined in your ApplicationController. Here's how to set it up:

class ApplicationController < ActionController::API
  def auth_header
    request.headers['Authorization']&.split&.last
  end

  def current_user
    Current.user = User.find_by_token_for(:auth_token, auth_header)
    @current_user ||= Current.user
  end
end

This setup allows you to:

Extract the authentication token from the request headers
Find the corresponding user
Make the user available throughout your GraphQL resolvers via context

You can then access the current user in any resolver or mutation:

module Mutations
  class BaseMutation < GraphQL::Schema::RelayClassicMutation
    def current_user
      context[:current_user]
    end

    def authenticate_user!
      raise GraphQL::ExecutionError, 'Not authenticated' unless current_user
    end
  end
end

Step 4: Configuring GraphiQL

Add GraphiQL configuration in config/initializers/graphiql.rb:

GraphiQL::Rails.config.header_editor_enabled = true
GraphiQL::Rails.config.title = 'Your API Name'

Update your config/application.rb to handle cookies for GraphiQL:

config.middleware.use ActionDispatch::Cookies
config.middleware.use ActionDispatch::Session::CookieStore
config.middleware.insert_after(ActionDispatch::Cookies, ActionDispatch::Session::CookieStore)

Step 5: Setting Up Routes

Add GraphQL routes to config/routes.rb:

Rails.application.routes.draw do
  post "/graphql", to: "graphql#execute"

  if !Rails.env.production?
    mount GraphiQL::Rails::Engine, at: "/graphiql", graphql_path: "/graphql"
  end
end

Step 6: CORS Configuration

If you're building an API, configure CORS in config/initializers/cors.rb:

Rails.application.config.middleware.insert_before 0, Rack::Cors do
  allow do
    origins "*"
    resource "*",
      headers: :any,
      methods: [:get, :post, :put, :patch, :delete, :options, :head]
  end
end

Best Practices

1. Structured Type Definitions

Organize your types in a modular way:

module Types
  class BaseObject < GraphQL::Schema::Object
    edge_type_class(Types::BaseEdge)
    connection_type_class(Types::BaseConnection)
    field_class Types::BaseField
  end
end

2. Implement Base Mutations

Create a base mutation class for common functionality:

module Mutations
  class BaseMutation < GraphQL::Schema::RelayClassicMutation
    argument_class Types::BaseArgument
    field_class Types::BaseField
    input_object_class Types::BaseInputObject
    object_class Types::BaseObject
  end
end

3. Error Handling

Implement consistent error handling across your GraphQL API:

module Mutations
  class BaseMutationWithErrors < BaseMutation
    field :errors, [String], null: true
    field :success, Boolean, null: false

    def handle_errors(record)
      {
        success: false,
        errors: record.errors.full_messages
      }
    end
  end
end

Testing Your Setup

After completing the setup, you can access GraphiQL at http://localhost:3000/graphiql in development. Try this query:

query {
  __schema {
    types {
      name
    }
  }
}

GraphiQL View in Rails

Security Considerations

Limit GraphiQL to non-production environments
Implement proper authentication
Use query depth limiting to prevent complex nested queries
Consider implementing rate limiting

Conclusion

With this setup, you have a solid foundation for building a GraphQL API in Rails. The included GraphiQL interface provides a powerful tool for testing and documenting your API during development.

Remember to:

Keep your schema well-organized
Implement proper error handling
Follow security best practices
Write comprehensive tests for your GraphQL endpoints

This setup provides a robust starting point for building scalable GraphQL APIs with Rails.

Happy Coding!
